Router 4p Cisco Rv340 Dual Wan Gigabit Vpn

Descripción

EXXA STORE
Mercadolider Platinum (100% de calificaciones positivas)

Distribuidor autorizado de Cisco en la Argentina (A)

ROUTER 4P CISCO RV340 DUAL WAN GIGABIT VPN

Products Specification

WAN ports
2 RJ-45 Gigabit Ethernet

LAN ports
4 RJ-45 Gigabit Ethernet RV340, RV340W
(LAN 1, 2, 3, 4 and LAN 9, 10, 11, 12 are PoE 802.3at, max 30W per port up to 120W total)

Console/serial
1 RJ-45 port for future use. Port is disabled

USB
2 for external 3G/4G modem or flash drive (USB-3, USB-2)

Firewall
Stateful packet inspection, up to 980 Mbps throughput for TCP and UDP

Quality of Service (QoS)
Traffic Classes, WAN Queuing, WAN Policing, WAN Bandwidth Management, Assign detailed QoS (Class of Service (CoS)/Differentiated Services Code Point (DSCP)/policies) settings per application or end device

Web Security
Dynamic web filtering: Cloud based, more than 80 categories, more than 450 million domains classified

Application Visibility
Application identification: Assign policies to Internet applications
500 unique Apps

Client Identification
Identifies and categorizes clients dynamically. Assigns policies based on end device category and operating system.

Intrusion Prevention System
IDS/IPS inspects network packets, logs and/or blocks a wide range of network attacks. It delivers increased network availability, faster remediation, and comprehensive threat protection.
HTTP/FTP/SMTP/POP3/IMAP

Antivirus
Protection from viruses, trojans, spyware, and identity theft by inspecting traffic going through the router.
HTTP/FTP/SMTP/POP3/IMAP

Cisco Umbrella
First line of defense for threats on the Internet. Prevention for user and malware-initiated connections. Protection against Malware, C2 callbacks, and phishing. Proxy inspection for risky domains.

IPSec
IKEv1 and IKEv2
50 simultaneous connections (any combination of remote access and site-to-site), up to 650 Mbps throughput

IPsec remote access
Yes (remote access from any standards-based IPsec client and Cisco IPsec VPN EasyVPN)

Layer 2 Tunneling Protocol (L2TP) over IPsec
Yes

Generic Routing Encapsulation (GRE) over IPsec
Yes

Cisco SSL VPN (Cisco AnyConnect)
Maximum 50 SSL VPN tunnels and up to 33Mbps throughput. Also requires Cisco AnyConnect end user licenses to use on the end device. Ideal for mobile devices.

Point-to-Point Tunneling Protocol (PPTP)
25 connections, up to 100 Mbps throughput

Teleworker mode (Cisco IPsec VPN)
Router acts as a client to connect to central VPN gateway in teleworker mode

VPN pass-through
IPSec, PPTP, L2TP

Management protocols
Web browser (HTTP/HTTPS)
Simple Network Management Protocol (SNMP) v1, v2c, and v3
Representational State Transfer (REST) API
NETCONF

Management Platform
FindIT Network Manager

Firmware upgrade options
Via local PC, USB stick, or from Cisco.com via web browser.
Unattended automatic firmware upgrade.

LAN

VLAN
Up to 32 VLANs

Port Security
Yes, 802.1X

Link aggregation
Yes (static, no LACP)

IPv6
Dual stack, 6rd, 6in4, Dual stack lite

WAN
DHCP client, static IP, PPPoE, PPPTP, L2TP, transparent bridge

Routing
Static routing, IGMP proxy, Inter-VLAN routing, Routing Information Protocol RIPv1,v2, RIPng

Network Address Translation (NAT)
Port Forwarding
Port Address Translation (PAT)
One-to-one NAT
VPN NAT traversal
Session Initiation Protocol (SIP) Application-Level Gateway (ALG), FTP ALG

NAT max sessions
>40000

NAT max connections per second
3000

DynDNS
ChangeIP.com, DynDNS.com, No-IP.com, dnsomatic

IPv6 transition
Dual Stack

Hardware DMZ
Yes (when enabled, one LAN port will be DMZ port)

DMZ host
Yes

SYSTEM

CPU
ARM-based architecture, dual core, hardware flow engine
1.2 Ghz (RV340W)
900 Mhz (RV345, RV345P, RV340)

RAM
1 GB DDR3

Flash
256 MB

WIRELESS

Standards
IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.11a, 802.1X (security authentication), 802.1Q (VLAN), 802.11i (WPA2 security), 802.11e (wireless QoS)

Antennas
4 external fixed paddle antennas (RV340W)

802.1X supplicant
Yes

SSID-to-VLAN mapping
Yes

Auto channel selection
Yes

WPA/WPA2
Yes, including enterprise authentication

Access control
Yes, MAC filtering

Rouge access point detection
No

QoS
Wi-Fi Multimedia (WMM) with unscheduled automatic power save

PERFORMANCE

Wireless throughput
PHY data rate:
2.4 GHz: 450 Mbps 964-QAM), 600 Mbps (256-QAM)
5 GHz: 1.7 Gbps (256-QAM), 2.1 Gbps (1024-QAM)
Total: Up to 2.7 Gbps
(real-world throughput will vary)

Recommended user support
Up to 50 users at 2.4 GHz and 124 users at 5 GHz simultaneously

Captive Portal for guest access
Yes

WIRELESS PARAMETERS

Frequency
Dual concurrent radios (2.4 and 5 GHz)

WLAN
802.11n/ac
4x4 MU-MIMO with 4 partial streams at 5GHz
3x3 MIMO with 3 spatial streams at 2.4 GHz
20 MHz, 40 MHz and 80 MHZ channels for 802.11ac
20 MHz and 40 MHz channels for 802.11n
PHY data rate:
2.4 GHz: 450 Mbps (64-QAM), 600 Mbps (256-QAM)
5 GHz: 1.7 Gbps (256-QAM), 2.1 Gbps (1024-QAM)
Total: up to 2.7 Gbps
802.11 Dynamic Frequency Selection (DFS)
MU-MIMO up to 3 clients simultaneously

Data rates supported
802.11 a/b/g:
? 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps
? 802.11n: 6.5 to 450 Mbps
- 20-MHz bandwidth: MCS 0-15 for supported data rates
- 40-MHz bandwidth: MCS 0-15 for supported data rates

802.11ac:
? 6.5 Mbps to 1.7 Gbps
- 20-MHz bandwidth: MCS 0-9 for supported data rates
- 40-MHz bandwidth: MCS 0-9 for supported data rates
- 80-MHz bandwidth: MCS 0-9 for supported data rates

Frequency band and operating channels
A (A regulatory domain):
2412 to ~2462 MHz: 11 channels
5.15 to 5.25 GHz: 4 channels
5.25 to 5.35 GHz: 4 channels
5.47 to 5.725 GHz: 8 channels
5.725 to 5.825 GHz: 5 channels
E (E regulatory domain):
2412 to ~2472 MHz: 13 channels
5.15 to 5.25 GHz: 4 channels
5.25 to 5.35 GHz: 4 channels
5.47 to 5.725 GHz: 8 channels
C (C regulatory domain):
2412 to ~2462 MHz: 13 channels
5.15 to 5.25 GHz: 4 channels
5.25 to 5.35 GHz: 4 channels

Transmitter output power
2.4 GHz
? 802.11b: 17.5 +/- 2 dBm
? 802.11g: 17.5 +/- 2 dBm @ 6 Mbps
? 802.11g: 15.5 +/- 2 dBm @ 54 Mbps
? 802.11n (HT20): 17.5 +/- 2 dBm @ MCS0
? 802.11n (HT20): 15.5 +/- 2 dBm @ MCS7
? 802.11n (HT40): 15.5 +/- 2 dBm @ MCS7

5 GHz
? 802.11a: 18.5 +/- 2 dBm @ 6 Mbps
? 02.11a: 14 +/- 2 dBm @ 54 Mbps
? 802.11n (HT20): 14 +/- 2 dBm @ MCS7
? 802.11n (HT40): 14 +/- 2 dBm @ MCS7
? 802.11ac (VHT80): 12.0 +/- 2 dBm @ VHT9SS

Wireless isolation
Wireless isolation between clients

Antenna gain in dBi
2.4 GHz: 3 dBi each antenna
5 GHz: 5 dBi each antenna

Receiver sensitivity
2.4 GHz
? 802.11b: -82 dBm @ 11 Mbps
? 802.11g: -71 dBm @ 54 Mbps
? 802.11n (HT20): -69 dBm @ MCS7
? 802.11n (HT40): -67 dBm @ MCS7

5 GHz
? 802.11ac (VHT20): -59 dBm @ MCS8
? 802.11ac (VHT40): -54 dBm @ MCS9
? 802.11ac (VHT80): -51 dBm @ MCS9

Wireless Distribution System (WDS)
No

PRODUCT DIMENSIONS
Excluding antennas: 280 x 44 x 170 mm (11 x 1.75 x 6.75 in)

Product weight device only


RV340: 960 g (2.1 lb)

MTBF
50000 hours

Rack mountable
Yes

Included accessories
Power supply, power cord, Ethernet cable, rack mount kit

Fan
No

Power Supply
AC 100-240V/1A DC 12V/2.5A DC

Certification
FCC Class B, CE Class B, UL, cUL, CB, CCC, BSMI, KC, Anatel

Operating temperature
0? to 40?C (32? to 104?F)

Storage temperature
0? to 70?C (32? to 158?F)

Operating humidity
10% to 85% noncondensing

Storage humidity
5% to 90% noncondensing
